This horizontal wind turbine system is designed for high-efficiency power generation in both onshore and offshore environments. Built with a strong alloy steel body, it ensures low vibration, durability, and long service life. The turbine features advanced aerodynamic glass fiber blades that maximize wind energy utilization, resulting in higher annual power output even at low wind speeds.
The system uses a patented permanent magnet generator, which reduces resistance torque and improves overall efficiency. A mechanical yaw system allows the turbine to automatically adjust wind direction, ensuring stable operation and protection during high wind conditions.
With anti-corrosion coating and weather-resistant materials, this turbine is suitable for harsh environments, including coastal and high-humidity areas.
Key Features
- Heavy-duty alloy steel structure (strong & durable)
- High-efficiency aerodynamic blades
- Low start-up wind speed (2.5 m/s)
- Permanent magnet generator for stable output
- Mechanical yaw system for automatic wind alignment
- Anti-corrosion, UV & salt-resistant coating
- Low noise and low maintenance design
Technical Specifications
- Rated Power: 4KW / 5KW / 7KW / 10KW / 12KW / 15KW
- Max Power: Up to 18KW
- Voltage Range: 96V – 380V
- Blade Material: Glass Fiber
- Blade Quantity: 3
- Wheel Diameter: 4.9m – 6.4m
- Start Wind Speed: 2.5 m/s
- Rated Wind Speed: 12 m/s
- Cut-in Speed: 3 m/s
- Survival Wind Speed: 45 m/s
- Generator Type: Three Phase Permanent Magnet Generator
- Protection Level: IP54
- Working Temperature: -80°C to +80°C
- Humidity: ≤90%
- Altitude Limit: ≤4500m
- Tower Type: Guyed Cable Tower
Applications
- Residential & Farm Installations
- Commercial & Industrial Power Supply
- Coastal & Offshore Projects
- Hybrid Solar-Wind Energy Systems
- Remote & Off-Grid Locations
Benefits
- Reduce electricity costs significantly
- Generate clean and renewable energy
- Reliable power even in low wind conditions
- Long lifespan with minimal maintenance
- Suitable for harsh weather environments
